剥锡铅液

一﹑产品简介
I Product Introduction

PC-556是单液型的剥锡铅液,以硝酸为主要成份,非常优秀的产品,能适合于以铜做为底材,电镀上锡铅金属或纯锡制品的镀层剥除用,适用范围很广,如:印刷电路板﹑IC制造﹑工业产品等行业。
PC-556 is a single-liquid tin-lead stripping solution with nitric acid as the main content and is a very good product; it can be applied for stripping the tin-lead or pure tin plating with copper as the base-material and has wide application scope, e.g., print circuit board, IC manufacture and industrial product.

二﹑产品优势
II Product Advantages

1、极少的沉淀;
1. Lettle deposit;
2、不伤害破璃纤维底材;
2. Not damage the base-material glass fiber;
3、使铜面光亮;
3. Polish copper surface;
4、可以使用自动添加系统;
4. Can use automatic adding system;
5、剥离速度很快,锡铅含量很高;
5. Rapid stripping velocity, high content of tin-lead;
6、不含氟化物,双氧水及其它有害化学物质;
6. Not contain fluoride, H2O2 and other harmful chemical substance;
7、适用于喷洒或浸泡的设备,维护管理容易,操作简单。
7. Be applicable for spraying or dipping equipment, easy maintenance and operation;

三﹑操作条件
III Operating Condition
组份/参数
Component/Parameter
最佳值/工作范围/要求
Optimal value/Work Scope/Requirement
浓 度
Concentration
全浓度
Whole concentration
温 度
Temperature
室温
Room temperature
时 间
Time
30秒-2分钟
30 seconds – 2 minutes
处理能力
Processing capacity
约35-45suface ft2/L
About 35-45suface ft2/L

四﹑槽液控制
IV Control of Solution

1、比重控制1.2-1.4(1.3-1.35最佳)
1. Specific gravity controlled as 1.2-1.4 (1.3-1.35 is better);
2、酸当量控制3.5N以上
2. Acid equivalent controlled as above 3.5N;

五﹑槽液分析方法
V Analysis Method of Solution

1、比 重:比重计 1.2-1.4
1. Specific gravity: hydrometer 1.2-1.4
2、酸当量分析
2. Analysis of acid equivalent
a、取5mL槽液加入100mL容量瓶中,加纯水稀释至标线位置;
a. Take 5ml solution and add it into a 100ml flask, and add pure water to dilute the solution to the designated level;
b、取5mL稀释液加入250mL锥形瓶中,再加纯水100mL;
b. Take 5ml diluted solution and add it into a 250ml conical flask, and then add 100ml pure water;
c、加3-5滴甲基红指示剂;
c. Add 3-5 drops of methyl red indicator;
d、用0.1N NaoH滴定,滴至溶液由红色变为黄色为终点。
d. Uuse 0.1N NaoH for titration till the solution turns from red to yellow;
计 算:酸当量(N)=0.1 × V0.1N NaoH(ml)× 4
Calculation: acid equivalent (N) = 0.1 × V0.1N NaoH(ml)× 4

六﹑产品性质
VI Product Nature
品名
product name
外观
Appearance
比重
Specific Gravity
酸当量
Acid equivalent
闪火点
Flash point
PC-556 黄褐液
Brown liquid
1.21±0.03 5.8N±0.5 不可燃
Non- combustible

七﹑安全防护
VII Safety Protection

PC-556为酸性液体,使用时请佩戴眼罩、手套及穿安全防护衣。若药液不慎溅及皮肤、眼睛时应用大量清水清洗,严重者应立即就医诊治。
PC-556 is acid liquid, and when using it, please wear eyeshade, gloves and protective clothes; in case that solution spatters into eye or on skin, immediately flush with plenty of clean water and get medical treatment if necessary.
